EPIC® MH BCEG 0.09 - 0.25sqmm D=0.8
Contact; Socket; Crimp termination; For cross-section (min./max.): 0.09mm² - 0.25mm²; Brass Gold-plated
EPIC® MH BCEG 0.09 - 0.25sqmm D=0.8
Rp 9.911,00
/
EPIC® MH BCEG 0.09 - 0.25sqmm D=0.8
Rp 9.911,00
/
Pembayaran & Keamanan
Informasi pembayaran Anda diproses dengan aman. Kami tidak menyimpan detail kartu kredit dan tidak memiliki akses ke informasi kartu kredit Anda.
Manfaat
Modular connector system, plugable with the market standard, Gold-plated contacts for low transfer resistance
Aplikasi
Mechanical and plant engineering, Robotics industry, Renewable energy, Railway applications / vehicle construction
Atribut Teknis
Informasi Umum
| Brand | EPIC® |
| Installation type | crimp |
| Product type | Contact |
| Contact delivery type | Bag |
| Delivery Unit | 100.000 |
| Weight | 0.014 kg |
Karakteristik Kelistrikan
Desain Produk
| Max. connectable conductor cross-section AWG | 24 AWG |
| Connectable conductor cross section min. (AWG) | 28 AWG |
| Max. connectable conductor cross-section (mm2) | 0.25 |
| Min. connectable conductor cross-section (mm2) | 0.09 |
| Conductor connection type | Crimp termination |
| Contact variant | Socket |
| Contact diameter | 0.8 |
| Contact material | Brass |
| Contact material, short form | CuZn |
| Material contact surface | Gold-plated |
| Contact coating material, short form | Au |
| Contact manufacturing method | Stamped |
| Stripping length of single core | 4.0 |
Karakteristik Produk
Sertifikasi dan Standar
| CE marked |
|
| CSA certified |
|
| cUR recognized |
|
| Tested for fire protection for railway vehicles |
|
| TÜV certified |
|
| UR recognized |
|
| VDE certified |
|
Dokumentasi
Further Links
Notes
- Photographs and graphics are not to scale and do not represent detailed images of the respective products.
- Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
